UCC23513DWYR

• Industrijski pogoni za upravljanje motorima

• Industrijska napajanja, UPS

• Solarni pretvarači

• Indukcijsko grijanje

The UCC23513 drivers are opto-compatible, singlechannel, isolated gate drivers for IGBTs, MOSFETs and SiC MOSFETs, with 4.5-A source and 5.3-A sink peak output current and 5.7-kVRMS reinforced isolation rating. The high supply voltage range of 33-V allows the use of bipolar supplies to effectively drive IGBTs and SiC power FETs. UCC23513 can drive both low side and high side power FETs. Key features and characteristics bring significant performance and reliability upgrades over standard opto-coupler based gate drivers while maintaining pin-to-pin compatibility in both schematic and layout design. Performance highlights include high common mode transientimmunity (CMTI), low propagation delay, and small pulse width distortion. Tight process control results in small part-to-part skew. The input stage is an emulated diode (e-diode) which means long term reliability and excellent aging characteristics compared to traditional LEDs. It is offered in a stretched SO6 package with >8.5mm creepage and clearance, and a mold compound from material group I which has a comparative tracking index (CTI) >600V. Visoke performanse i pouzdanost UCC23513 čine ga idealnim za upotrebu u svim vrstama motornih pogona, solarnih invertera, industrijskih izvora napajanja i uređaja.

Viša radna temperatura otvara mogućnosti za aplikacije koje ranije nisu mogle biti podržane tradicionalnim optospojnicama.
